5-tubes 1 vaporizer Multifunctional Anesthesia machine
Introduction:
YJ-8501 anaesthesia machine is equipped with a precise and dedicated anaesthetic vaporiser and safety devices to prevent cyanosis and the necessary alarm system.
During anaesthesia, the patient's respiratory function can be managed with a microcomputer-controlled pneumatic-electric synchronous anaesthetic ventilator.
Every connection part of the entire machine is a standard interface.
The efficient large volume soda-lime absorber minimises the patient's re-inhalation of carbon dioxide.
Pneumatically driven and electrically controlled system Built-in ventilator,
5.4” LCD display screen
Closed; Semi-Closed; Semi-Open working mode
Applied for Adult and Pediatric
Main technical specifications:
Pneumatically driven and electrically controlled system
Gas requirement: Medical oxygen and nitrous oxide with a pressure ranging from O2 & NO2: 0.32~0.6 MPa.
Respiration Mode: A/C,IPPV,SIPPV,IMV,SIMV,VCV,PCV,PEEP,SIGH,MANUAL
Alarm parameters: upper/lower limit of airway pressure,tital volume exceed limitation,no tidal volume output,apnea,AC power malfunction,Battery low power.
Parameters | |
Built-in ventilator | YES |
Display screen | 5.4” LCD display screen |
Wotking mode | Closed; Semi-Closed; Semi |
Application | Adult and Pediatric |
5-tubes Flowmeters | O2 & N2O & Air ; 0.1L/Min ~ 10L / Min |
Oxygen Flush | 25~75 L / Min |
Tidal Volume | Adjustable range:20 ~ 1500 ml, Display range:0~2000ml |
I/E Ratio | 8:1 ~ 1:10 |
Two vaporizers | Enflurane/ Isoflurane/Sevoflurane/Halothane |
Vaporizer Setting Range | 0.5%~5% |
Respiration Frequency | 1~100 bpm |
Lung compliance | ≤30 mL / kPa |
IMV frequency | 1~20 bpm |
PEEP | 0 ~ 2.0 kPa |
Ptr | -1.0kPa ~ 2.0 kPa |
CO2 absorber capacity | 1KG |
Inspiratory Plateau | 0~1 S |
O2 Concentration | 21%~100% |
Patient monitor | Optional |
