OIP Infusion Pump
Features:
1. 4.3" color TFT LCD screen (LED backlight), with resolution 272×480
2. Three working modes: Rate/Time/Volume mode
3. Drug library with 210 kinds of medicine
4. Storage 1500 history records
5. Heating function, suitable for infusing in winter or there is requirement for the fluid medication temperature
6. Support multi language display
7. A variety of visible and audible alarm, make infusion more safe Standard:Drug library, History record, Heating function, Drip detector ,Remote control
Hot Tags: hospital infusion pump, China, suppliers, manufacturers, factory, low price
| Adjustable drop rate range | 1 /min~400 drops/min (step: 1 drop /min) |
| Adjustable flow rate range | 1ml/h~1200ml/h (step 0.1ml/h) |
| Purge rate | 800ml/h |
| KVO rate | 1ml/h (less than 100ml/h) 2ml/h (100~300ml/h) 3ml/h (greater than 300ml/h) |
| Infusion volume range | 1ml~9999.9ml (step: 0.1 ml) |
| Maximum accumulated volume | 9999.9ml (step: 0.1 ml) |
| Infusion Time range | 1min~9999min (step: 1 min) |
| Infusion accuracy | Within ±3% (using calibrated high quality IV set) |
| Mechanical precision | within ±2% |
| Occlusion alarm threshold |
High: 800 mmHg ± 200 mmHg (106.7kPa±26.7kPa) Medium: 500 mmHg ± 100 mmHg (66.7kPa±13.3kPa) Low: 300 mmHg ± 100 mmHg (40.7kPa±13.3kPa) |
| Alarm | Infusion Complete, Empty, Faulty Signal, Misoperation, Occlusion, Door Open, Air Bubble, Low Battery, Setting Error, AC power off, Idle. |
