Heart Ultrasound

*Main screen 15" medical HD monitor
*Flexible monitor bracket
*All-in-one keypad
*Detachable probe hanging slot
*Front double pull handle
*Flexible caster,directional locking
*One-piece body structure

Send Inquiry

Chat Now

Description

Technical Parameters

Products Description

Heart Ultrasound-YJ-P8

New Generation Intelligent Internet Color Ultrasound

Introducing the YJ-P8, a state-of-the-art cardiac ultrasound system with advanced imaging capabilities and user-friendly design, revolutionizing cardiovascular diagnostics.

Features

*Main screen 15" medical HD monitor

*Flexible monitor bracket

*All-in-one keypad

*Detachable probe hanging slot

*Front double pull handle

*Flexible caster, directional locking

*One-piece body structure

IMAGE PROCESSING FUNCTION --- PSEUDO COLOR

It is a way to change the display mode of black and white images into color display.

PSEUDO COLOR

Since the human eye is not very sensitive to the resolution of gray scale levels, the sensitivity of the human eye to different echo intensities can be enhanced after the black and white images are converted to color. Subjectively, the dynamic range of the display signal is increased, and the recognizability of the image boundary is enhanced.

Technical Features:

* 3D/4D imaging technology
* Probe automatic recognition intelligent monitoring
* Digital continuous beamforming
* Backlit keyboard, convenient operation process
* Comes with Wifi connection and Internet telemedicine
* Professional color ultrasound workstation operating software
* Support beautiful graphic report printing
* Powerful measurement software package

Products parameters

Technical parameters:

Application description and cargo requirements:
Meet the examination and diagnosis of primary hospitals in abdominal, obstetrics, gynecology, heart, urinary system, small organs, superficial, blood vessels, pediatric physical examination and other aspects.

Main specifications and system overview:

Operating system: based on ARM System, stable, simple and power

Support three probe sockets, which can select the inspection site

Display mode: B, B+B, B+M, M, 4B;

Display screen: 15-inch 1024*768 resolution high-definition LED LCD screen

System language: Chinese and English, Spanish, French

machine size: 579.1 * 710.69 * 1220.33mm

Net weight: 46 kg

Probes:

Convex array probe (C3-2): frequency 2.0MHz/2.5MHz/3.5MHz/5.0MHz/,four-stage frequency conversion, the center frequency is 3.5MHz,each frequency conversion corresponds to the corresponding harmonic frequency (depth adjustment: ≥19 level, adjustment range 50-280mm)

Linear array probe (L3-2): frequency 6.5MHz/7.5MHz/8.5MHz/9.0MHz, four-stage frequency conversion, the center frequency is 7.5MHz,
each frequency conversion corresponds to the corresponding harmonic frequency (depth adjustment: ≥6 levels , adjustment range 50-100mm)

Transvaginal probe (EC1-2): frequency 4.0MHz/5.0MHz/6.5MHz/8.0MHz, four-stage frequency conversion, the center frequency is 6.5MHz, each frequency conversion corresponds to the corresponding harmonic frequency (depth adjustment: ≥6 levels , adjustment range 50-100mm)
