Convex array probe B/W laptop china portable ultrasound machine
Product Show:
Main Features:
Powerful measurement & calculation software packages
8-Segment TGC ABD Trackball adjustment
12 inch LCD monitor
Permanent function of image store: 32 images
2 probe connectors
Probe automatic identification
Introduction of Laptop Ultrasound Scanner YJ-U100 B：
Ultrasound Doppler Ultrasound Scanner can be used for abdomen, gynecology, obstetrics, cardiology, small parts, urology
It’s easy to carry and have good image quality.
Specifications of Laptop Ultrasound Scanner YJ-U100 B:
Main Technical Specification:
Scanning mode: Convex/Linear/Micro-convex/Trans-rectal;
Display modes: B, B+B, B+M, M, 4B;
Scanning depth: 240mm;
Gray scales: 256;
Function of image magnification: image zoom (real-time status under B mode), up to 5 times (area); local amplification function which can be enlarged under the real-time and froze;
Image conversion: up/down, left/right, black/white;
Function of puncture guide;
Max dynamic range>=100db;
Detecting depth>=190mm, scanning depth>=240mm;
The geometric location accuracy: vertical<=5%; lateral<=5%; blind spot: <=4mm;
Vertical resolution: <=1mm (depth<=130mm) < =2mm (130mm<depth<170mm);
Lateral resolution: <=1mm (depth<=130mm) < =2mm (130mm<depth<160mm);
Gamma: 4 gray scale γ transform function;
Variety of focus selection and multi-stage dynamic focusing with 4 transmit focus; support to launch multi-focus combination;
Built-in pseudo color processor, Pal-D and VGA video output, can connect external screen monitors, color monitors, VCRs, video image printer and other equipment.
Fixed characters and real-time clock and calendar display;
Software reset function;
Printer function: can connect laser printer and Video printer directly;
Comment: Date, Name, Sex, Age, Hospital, Annotation;
Zooming: *1.0, *1.2, *1.5, *2.0;
Port: USB 2.0, VGA, Video connector;
Measurement:
General menu: Distance, Area, Volume, Angle, Ellipse;
Obstetrics menu: GS, CRL, BPD, HC, AC, FL, Fetus Weight;
Heart menu: Distance, Time, Slope, Rhythm;
USB Function of image store: more than Sixteen thousand images;
Power supply: AC 110V-240V, 50HZ/60HZ;
Probe connector: 2;
USB/VGA/ ports;
Video printer connector;
Standard configuration:
12 inches LCD main unit 1set;
60R/3.5MHZ Convex array probe 1pc;
Power line 1pc;
Ground line 1pc;
Fuse 4 pc;
User’s manual in English 1pc;
Warranty card 1pc;
Options:
L40/7.5MHZ Linear array probe;
20R/5.0MHZ Micro-Convex array probe;
6.5MHZ Transvaginal l probe;
Mitisubishi Video Printer;
Inside battery(3hours)
Q: What is your Minimum Order Quantity?
Our Minimum Order Quantity (MOQ) is generally 1 unit. The exception however is that for certain items (e.g. wires, gloves or tubing) the MOQ may vary. Feel free to contact us to get a exact MOQ for your product.
Q: Which payment methods do you accept?
We accept most forms of monetary payment such as bank transfer, T/T, direct transfer, L/C and Western Union. Please get in touch with one of our sales managers to check if your payment option is acceptable.
