Bipolar Vessel Sealing Device

YJ-VS100E  Bipolar Vessel Sealing Device

Real time Instant Power technology features an advanced feedback system that recognizes changes in tissue 1,000 times per second.

The generator automatically senses tissue resistance and adjusts the output voltage to maintain a consistent
effect across different tissue density.This adjustment is based on the power setting and the level of tissue resistance.

The maximum output voltage is controlled to reduce tissue damage and to minimize sparking.The generator produces a highcurrent,
low-voltage output that corresponds to at least four times the current of a standard electrosurgery generator,

with one-fifth to one-twentieth the amount of voltage.


YJ-VS100E Bipolar Vessel Sealing Device

Clinical Benefits for Both the Surgeon and Patient

1. Permanently fuses vessels up to and including 7 mm in diameter
2. Tissue bundles without dissection or isolation
3. Reduces the risk of needle stick injuries,Reduces thermal spread ,Minimizes thermal spread to approximately 1~ 2 mm for most instruments.
4. Unique energy output results in virtually no sticking or charring
5. Permanent seal leaves no foreign material behind to interfere with future diagnosis .
6.Potential time savings compared to suture.
7. A clinical study demonstrated that seals withstand 3x normal systolic blood pressure
8. May reduce blood loss in some surgical procedures. Minimizes the need for multiple applications.

successful cases

Choose the plan that suits you best.

Panel with one instrument plug in

1-sealing indicator light

2-sealing levels

3-cutting indicator light
4-cutting levels

5-volume down

6-volume up

7-speaker value

Panel with two instruments plug in

Contraindication

1) Serious heart and lung function not complete.
2) Disturbance of blood coagulation.
3) Acute diffuse peritonitis.
4) Abdominal adhesion.
5) Vascular diameter over 7mm.
6) Sterilization operation in tubal ligation or tubal coagulation.

Power supply out put setting

Switch power on and plug in the instrument,touch
screen will show up.Optimal default power output is
showing on the screen three squares are color blue
(seal) or yellow (cut).If need add or reduce the
power out put,touch the first square two times,then
tap the folowing square toreach the numbers needed.

Recognizein struments

Blue socket 1,instrument activity by handpiece control button (without footpedal control).
Gray/purple socket2,instrument activity by both handpiece control button and footpedal control.
