B/W Trolley Ultrasound System Scanner
Introduction of Trolley Ultrasound Scanner YJ-U360T：
YJ-U360T Trolley B/W Ultrasound Scanner supports displays in real time, frozen, amplified, black- white reversed, up and down conversed and shift depth in real time. That having PAL, VGA video output, Soft keyboard and track ball operation system, trolley structured with plastic cover. The device is applicable for hospitals and clinics for examining liver, GB, spleen, kidney, pancreas, heart, bladder, uterus, etc.
Specifications of Trolley Ultrasound Scanner YJ-U360T
The main feature of Trolley Ultrasound Scanner YJ-U360T: |
The image can be displayed in real time, frozen, amplified, black- white reversed, up and down conversed and shift depth in real time. |
Video output is standard PAL and VGA; it is easily accessed to the equipment, such as the large screen monitor, videocassette recorder, video image printer, etc. |
Soft keyboard and track ball to make operation faster, convenient and flexible. |
The device is trolley structured with plastic cover. Switch power is used without working frequency transformer. |
FPGA and SMT in the device make the device high integrated, small volume and light weight. |
The device passed clinical verifications of safety and diagnosis validity in its manufacturing country. |
Chinese-English conversation. |
The specific of Trolley Ultrasound Scanner YJ-U360T: | |
Display Depth (mm) | ≥220 |
Resolution(mm) | Lateral, ≤3(depth≤80), ≤4(80<depth≤130); Axial, ≤2(depth≤80), ≤3(80<depth≤130) |
Dead Zone (mm) | ≤5 |
Geometry precision (%): Horizontal | ≤15; Vertical: ≤10 |
Monitor screen | 14 inch |
Display mode | B, B+B, B+M, M |
Image gray scales | 256 scales |
Electronic focusing | 4 focuses combination randomly |
Magnification | x1.0, x1.2, x1.5, x2.0 |
Cine-loop | 186 or 236 frames |
Image storage | 20 frames |
Pseudo-color unit | inside |
Image reverse | left/right, black/white, up/down |
Local Zoom | 2 times |
Depth shift | B, B+B modes real time shift |
Powder supply | 100V-130V/220V-240V, 50/60Hz |
Fetures of Trolley Ultrasound Scanner YJ-U360T：
Standard Configuration:
Scanner Body: 1pc
3.5Mhz Convex Probe: 1pc
Charger with a set of wires: 1set
Bottle of USG gel: 1pc
User Manual: 1pc
Optional
| 5.0MHz Micro-convex Probe |
6.5MHz Trans-vaginal Probe | |
7.5MHz Linear Probe | |
Video Printer |
FAQ：
Q:What is time of delivery?
A:Since our products are produced according to each specific order, the delivery period will be 15days after confirmation of order. If it is small or sample order, please do check with us about whether we have ready goods in stock to make delivery as soon as possible.
Q:What about quality assurance?
We offer one year warranty period beginning from the time of shipment for medical equipment, Per minor problems, we can provide free spare parts for replacements, Per serious problems, we can make replacement of free charge. But if the machine is damaged due to rough handling during the transportation, we are free of any responsibility, but we will still provide help to the buyer issue claims against the shipping company or insurance company, thus all the spare parts or expenses should be borne by buyer.
Q:What is payment terms?
A:T/T in advance, Western Union
Q:Which shipping company usually using?
A:MAERSK-LINE, PIL, COSCO, SAFMARINE, MARUBA, APL, CMA, CSAV, K-LINE, MSC, NYK, AND DHL, EMS, TNT, UPS FOR COURIER, buyer's option will be our priority, we will give suggestion according to the schedule and services.
Delivery and Package:
