Black and White Hybrid Video Graphic Printer
The UP-X898MD printer is a hybrid model accepting both analog and digital signal inputs.
UP-X898MD offers "PRINT, STORE and GO" capabilities with Sony's IMAGEPORT™ interface.
This allows users to either print image store them on a USB drive and transfer them to a laptop.
This black and white ultrasound printer is designed for today' s advanced ultrasound systems with high speed printing times of approximately 1.9 seconds, high resolution of 325 DPI and a compact-space-saving design.
Highlights:
Hybrid - accepts both analog and digital signal input
Ideal for today’s advance ultrasound systems
Unique built-in digital capture enables you to store images on a connected USB drive
Sony’s IMAGEPORT™ interface is now incorporated into the UP-X898MD
Print-----Store----Go
1.9 Second print speed
User-friendly controls on front panel
Uses same media as the UP-895 and UP-897 series printers
High-quality, photo like images
Specifications:
Connector: Analog
Dimensions: 6 1/8 x 3 1/2 x 9 1/2 inches
Gradation: True 256 gray balance
Interface: Input connector: VIDEO IN (BNC type) NTSC or PAL composite video signals 1.0 Vp-p, 75
ohms (NTSC/PAL automatically discriminated) Output connector: VIDEO OUT (BNC type) Loop-through
Remote connector: stereo mini jack USB
Picture Memory: 10 Frames
Power Requirements: 100 to 240 V AC 50/60Hz 1.5A to 0.8A
Print Media: UPP-110S/5,UPP-110HD, UPP-110HG
Print Speed: Approximately 1.9 seconds (High Speed Mode)
Printer Driver Software: OS: Windows® 2000/XP
Printing Method: Direct Thermal Printing
Resolution: 325 dpi
Safety Compliance: UL60950-1 Listed
CSA C22.2 No. 60950-1
UL60601-1 Listed
CSA No. 60601-1
Thermal Head: Thin film thermal 1280 dots
Type: Black White Printer
Weight: Approximately 5lb. 12 oz
